Our engineering team integrates the Holykell HRS10 tipping-bucket rain sensor into your existing systems. Holykell engineered this high-precision instrument specifically for advanced weather monitoring. The device accurately collects precipitation to measure total rainfall. It then converts the collected water into precise digital pulse signals. We directly connect these signals to your preferred data logging systems. This professional integration ensures seamless data transmission, continuous recording, and real-time processing.
Key Features & Technical Specifications:
-
Measurement Resolution: The system features either 0.1 mm or 0.2 mm per tip configurations.
-
Accuracy: The instrument achieves ≤ ±2% to ±3% for highly reliable rainfall measurement.
-
Construction Material: Holykell builds the main cylindrical body from SS304 stainless steel. This robust material ensures excellent corrosion resistance and outdoor durability.
-
Signal Output: Our team configures RS485, Modbus, Pulse, 0–5 V, 0–10 V, or 4–20 mA outputs.
-
Operating Voltage: The sensor operates perfectly on a flexible 4.5–30 V DC power supply.
-
Rainfall Collection Inlet: The device features a standard 200 mm diameter collection funnel.
-
Maximum Rainfall Intensity: The equipment continuously measures rainfall intensity up to 4 mm/minute.
-
Operating Temperature: The hardware functions optimally between 0 °C and 50 °C.
-
Rain Collection Funnel Material: You can select either ABS plastic or SS304 stainless steel funnels.
-
Brand: Holykell.
-
System Customization: Our automation engineers customize the entire setup to meet your specific project requirements.
